RM125

The RM125 is the latest 125 watt base station in the Micom series of software defined HF transceivers.  It is capable of operation on any frequency in the 1.8-30 MHz range.  The 3 series radios have a larger display and were made with more computing power which supports enhanced features. The unit has been tested & certified by DOD's Joint Interoperability Test Center (JITC) for compliance with MIL-STD-188-141B, the Automatic Link Establishment (ALE) standard used by the U.S. and most of the world.  The RM125 is designed for installation in a 19 inch rack or on a table-top and includes a 110/220 VAC automatic switching power supply.  The unit has a 12 VDC output on the rear to charge a standard 90 amp battery and will automatically switch to this battery in the event of failure of the AC power.  The RM125 is available with embedded type-3 AES encryption for both voice & data.  This base station is available with local, extended local and internet control options.  See options list for other available features.

Link to brochure ( RM125.pdf  )

______________________________________________________________________________

RM125R

The RM125R is the latest ruggedized 125 watt base station in the Micom series of software defined HF transceivers.  It is capable of operation on any frequency in the 1.8-30 MHz range.  The 3 series radios have a larger display and were made with more computing power which supports enhanced features. The unit has been tested & certified by DOD's Joint Interoperability Test Center (JITC) for compliance with MIL-STD-188-141B, the Automatic Link Establishment (ALE) standard used by the U.S. and most of the world.  The RM125R is designed for installation in a 19 inch rack or on a table-top and includes a 110/220 VAC automatic switching power supply.  The unit has a 12 VDC output on the rear to charge a standard 90 amp battery and will automatically switch to this battery in the event of failure of the AC power.  The RM125R is available with embedded type-3 AES encryption for both voice & data.  This base station is available with local, extended local and internet control options.  See options list for other available features.

Link to brochure ( RM125R.pdf )

______________________________________________________________________________

RM500

The RM500 is the latest 500 watt base station in the Micom series of software defined HF transceivers.  It is capable of operation on any frequency in the 1.8-30 MHz range.  The 3 series radios have a larger display and were made with more computing power which supports enhanced features. The unit has been tested & certified by DOD's Joint Interoperability Test Center (JITC) for compliance with MIL-STD-188-141B, the Automatic Link Establishment (ALE) standard used by the U.S. and most of the world.  The RM500 is designed for installation in a 19 inch rack or on a table-top and includes a 110/220 VAC automatic switching power supply.    The RM500 is available with embedded type-3 AES encryption for both voice & data.  This base station is available with local, extended local and internet control options.  See options list for other available features.

Description:

Link to brochure (RM500.pdf)

__________________________________________________________________

RM500R

The RM500R is the latest ruggedized 500 watt base station in the Micom series of software defined HF transceivers.  It is capable of operation on any frequency in the 1.8-30 MHz range.  The 3 series radios have a larger display and were made with more computing power which supports enhanced features. The unit has been tested & certified by DOD's Joint Interoperability Test Center (JITC) for compliance with MIL-STD-188-141B, the Automatic Link Establishment (ALE) standard used by the U.S. and most of the world.  The RM500R is designed for installation in a 19 inch rack or on a table-top and includes a 110/220 VAC automatic switching power supply.  The RM500R is available with embedded type-3 AES encryption for both voice & data.  This base station is available with local, extended local and internet control options.  See options list for other available features.

Link to brochure RM500R.pdf

Micom Accessories

Military type external speaker for Micom R series radios...............click for brochure LS454.pdf

Military type handset for Micom R series radios..............................click for brochure (H250.pdf)

Headset/microphone for non-R series radios....................................under development

Remote Speaker with Call Indicator & Headphone Jack....................under development
